Dryer

Drying machine technical parameters:

1, Product Microwave Model: QX-60HM9

2, the input power supply: three-phase five-wire 380V ± 10% 50Hz ± 1%

3, the microwave output power: 60kW (adjustable)

4, the microwave frequency: 2450MHz ± 50Hz

5, Rated input apparent power: ≤ 90kVA

6 out height: 80mm

7, the transmission width: 912mm

8, the transmission speed: 0.1 ~ 5m/min

9, Dimensions (L × W × H): about 17030 × 1555 × 1668mm

10, the working environment: 0 ~ 40 ℃, relative humidity ≤ 80%

11, in line with GB 10436-1989 Hygienic standard workplace microwave radiation

12, in line with GB/5226.1-2002 Safety of machinery - Electrical equipment

Dryer according to the user's actual production to design and manufacture products of different specifications microwave dryers and hot air circulation dryer. I have a microwave dryer experimental prototype, and hot air circulation dryer, free on-site production operations, combined with consumer products provide one-stop technical services, welcomed the new and old friends to visit and negotiate.
